MIL-DTL-16377/53D
TABLE III. Part number and general information.
Military Part
National Stock
Item Name
Remarks
Number M16377/53
Number (NSN)
1/, 2/
-100.2
Complete lantern, Symbol 100.2
1/, 3/
-101.2
Complete lantern, Symbol 101.2
1/, 4/
-102.2
Complete lantern, Symbol 102.2
1/, 5/
-108
Complete lantern, Symbol 108
1/, 6/
-100.3
Complete lantern, Symbol 100.3
1/, 7/
-101.3
Complete lantern, Symbol 101.3
001
Body assembly
6230-00-783-6519
002
Handle assembly
5340-00-776-5920
003
Bracket assembly
6230-00-968-7831
004
115 VAC relay assembly
5945-00-783-6251
005
115 VDC relay assembly
5945-00-783-6252
006
220 VDC relay assembly
5945-00-783-6253
007
Cover gasket, figure 18
5330-01-346-8127
008
Rechargeable retrofit kit - Bulkhead
6220-01-481-3827
Includes rechargeable top
plate assembly
009
Rechargeable battery
6140-01-463-4470
Purchased separately
010
LED upgrade kit - White
6230-01-531-7844
011
Rechargeable retrofit kit - Portable
Includes rechargeable handle
assembly
012
Rechargeable Handle Assembly
Included in rechargeable
retrofit kit Portable
013
115 VAC Rechargeable; top plate assembly
Included in rechargeable
retrofit kit Bulkhead
014
LED upgrade kit - Red
6230-01-531-7845
015
Switch, pushbutton
NOTES:
1/
Lanterns are not furnished as complete units. Complete lanterns shall be assembled using the component parts indicated.
a. Lanterns are intended to be mounted onboard ship as shown on figure 2.
b. Lanterns over surgical tables onboard ship are intended to be mounted using the adjustable bracket shown on
MIL-F-16377/55.
c. Color filters, MIL-F-16377/43, shall be used to convert white (clear) light incandescent lanterns into colored light
lanterns.
2/
Symbol 100.2 consists of part numbers: M16377/53-001, M16377/53-002, M16377/53-003, and M16377/53-013/014 if
LED (LED becomes Symbol 100.2L).
3/
Symbol 101.2 consists of part numbers: M16377/53-001, M16377/53-004, and M16377/53-013/014 if LED (LED
becomes Symbol 101.2L).
4/
Symbol 102.2 consists of part numbers: M16377/53-001, M16377/53-005, and M16377/53-013/014 if LED (LED
becomes Symbol 102.2L).
5/
Symbol 108 consists of part numbers: M16377/53-001, M16377/53-006, and M16377/53-013/014 if LED (LED
becomes Symbol 108L).
6/
Symbol 100.3 consists of part numbers: M16377/53-001, M16377/53-003, M16377/53-009, M16377/53-010, and
M16377/53-013/014 if LED (LED becomes Symbol 101.3L).
7/
Symbol 101.3 consists of part numbers: M16377/53-001, M16377/53-008, M16377/53-009, and M16377/53-013/014 if
LED (LED becomes Symbol 101.3L).
30
