INCH-POUND

MIL-DTL-16377/53D

30 June 2014

SUPERSEDING

MIL-DTL-16377/53C

27 September 2005

DETAIL SPECIFICATION SHEET

FIXTURES, LIGHTING; INCANDESCENT AND LIGHT EMITTING DIODE (LED),

DETAIL LIGHTING, LANTERN, HAND, PORTABLE AND BULKHEAD MOUNTED, WATERTIGHT,

SYMBOLS 100.2, 100.2L, 100.3, 100.3L, 101.2, 101.2L, 101.3, 101.3L, 102.2, 102.2L, 108, AND 108L

This specification is approved for use by all Departments and Agencies of the Department of Defense.

The requirements for acquiring the product described herein shall consist of this specification sheet and

MIL-DTL-16377.

NOTE: Unless otherwise specified, all dimensions are in inches on figures 3 � 22.

FIGURE 1. Lanterns, hand, portable and hard wired/bulkhead mounted.

AMSC N/A

FSC 6230
