MIL-DTL-16377/53D
EXAMINATION AND TESTS:
Examination and tests shall be as specified in MIL-DTL-16377 and as follows:
First article inspection:
Body assembly:
See table II.
Handle assembly:
See table II.
Rechargeable handle assembly:
See table II.
Rechargeable retrofit kit:
See table II.
LED upgrade kit:
See table II.
Bracket assembly:
Examination only.
Conformance:
Comparison inspection:
Same as first article inspection.
Conformance inspection:
See MIL-DTL-16377.
GENERAL INFORMATION:
Assignment of military part numbers and general information is shown in table III.
TABLE II. Required first article testing for battle lanterns. 1/
Test
Requirement
Test Method
Remarks
2/, 3/
Dielectric withstanding voltage
3.6.15
4.8.2
2/, 3/
Insulation resistance
3.6.16
4.8.3
2/, 4/
Enclosure effectiveness
3.5.11
4.8.14.4
Grade A, 2/
High impact shock
3.5.12
4.8.7
2/
Vibration
3.5.13
4.8.8
2/, 4/
Enclosure effectiveness
3.5.11
4.8.14.4
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
5/
Mechanical shock
3.7.7.6
4.8.17.3
5/
Thermal shock
3.7.7.7
4.8.17.4
(glassware/plastics)
3/
Power interface
3.6.18
4.8.21
Light output
3.7.1
4.8.6.1
6/
Electromagnetic interference
3.6.14
4.8.16
NOTES:
1/
Requirement and test method paragraph numbers refer to MIL-DTL-16377.
2/
In accordance with 4.3.1 of MIL-DTL-16377, tests shall be performed on one luminaire in the
order specified.
3/
Test required only for Symbols 100.3, 100.3L, 101.2, 101.2L, 101.3, 101.3L, 102.2, 102.2L,
108, and 108L.
4/
Watertight.
5/
Only for LED lens regardless of lens material.
6/
Charger/control module only. Only tests RE 101, RE 102, CE 101, and CE 102.
