MIL-PRF-44259E
f. That any crimp-type electrical fasteners are secure on the wires and that no wire
strands are broken or not secured within the fastener.
g. That wiring schematic is displayed in ballast chamber.
Whenever nonconformance is noted, correction shall be made to the item affected and the
process. Items, which cannot be corrected, shall be removed from production.
4.3.3 End item visual examination. The end items shall be examined for the defects
listed in table II. The lot size shall be expressed in units of complete light sets. The sample unit
shall be one complete light set. The verification levels shall be IV for major defects and II for
minor defects.
TABLE II. End item visual defects.
Classification
Examine
Defect
Major Minor
Finish
Not adherent, e.g., blistered, peeled, or
201
flaky
Coating not continuous or uniform
202
i.e., not coated or area of no film
Scratch, dig, or abrasion exposing bare
203
metal or primer
Color
Not color specified
101
Electrical cable
Not proper size or type
102
Cut or abrasion
103
Electrical connector
Missing or not correct part number
104
Light straps
Not as specified
105
Design and workmanship
Sharp edge or burr
106
Puncture, fracture, or malformed
107
Design detail deviating from document
108
Evidence of rust or deposit of any foreign
204
matter
Light switch
Missing, in-operable, or not correct switch
109
Light switch weather boot or
Missing, ripped, torn or cracked
205
covering
Markings or labels
Omitted, incorrect, illegible, misplaced
206
9
