MIL-PRF-44259E
4.3.4 End item dimensional examination. The light set shall be examined for
dimensional defects listed in table III. The lot size shall be expressed in units of complete light
sets. The sample unit shall be one complete light set. The verification levels shall be IV for
major defects and II for minor defects.
TABLE III. End item dimensional defects.
Classification
Examine
Defect
Major Minor
Overall dimensions
Smaller than specified less applicable minus
101
(individual light assemblies)
tolerance
Larger than specified dimensions and
102
applicable plus tolerances
Overall dimensions
Dimensions not as specified
103
4.3.5 End item testing. The complete light set shall be tested for the characteristics listed
in table IV. The lot size shall be expressed in terms of complete light sets. The sample unit shall
be one complete light set. The verification level shall be IV.
TABLE IV. End item tests.
Characteristic
Requirement
Test method
paragraph
Current draw
3.4.3
4.4.5
Electrical continuity
3.4.9
4.4.8
4.3.6 Packaging examination. The fully packaged end items shall be examined for the
defects listed in table V. The lot size shall be expressed in units of shipping containers. The
sample unit shall be one shipping container fully packaged. The verification level shall be IV.
TABLE V. End item examination.
Examine
Defect
Marking
Omitted; incorrect; illegible; of improper size, location, sequence
(interior and exterior)
or method of application
Materials
Any component missing, damaged, or not as specified
Workmanship
Inadequate application of components, such as: incomplete
sealing or closure of flap, improper taping, loose strapping or
inadequate stapling
Content
Number of light sets per shipping lot is more or less than required
10
