MIL-DTL-16377/17B(SH)

EXAMINATION AND TESTS:

Examinations and tests shall be as specified in MIL-DTL-16377 and the following:

First article inspection:

Complete fixtures:

See table II for Type I and table III for Type III.

Conformance:

Comparison inspection:

Same as first article inspection.

Conformance inspection:

See MIL-DTL-16377.

GENERAL INFORMATION:

Assignment of military part numbers and general information is shown in table IV.

TABLE I. Standard Parts.

Specification or Military

National Stock

Name

Remarks

Part Number

Number (NSN)

Lamp

ANSI/ANSLG C78.81

6240-00-299-5546

Industry Number

F8T5/CW

Lamp lock

M16377/40-001

6250-00-399-7039

Lampholder

UL 496

6250-00-377-8590

SUPP. SA, FIG. SA2.1

Startersocket

UL 496

6250-00-295-2738

SUPP. SA, FIG. SA2.4

Starter

NEMA ANSI C78.180

6250-00-299-5962

Commercial

Designation: FS5

Ballast

M16377/45-001

6250-00-295-2735

Switch, toggle, DPST

MS16569-1

5930-00-719-9659
