MIL-DTL-16377/17B(SH)
TABLE IV. Part number and general information.
Military Part
National Stock
Number
Item Name
Remarks
Number (NSN)
M16377/17-
1/ 2/
229.1
Complete light, Symbol 229.1
6230-01-240-1105
1/ 2/
231.1
Complete light, Symbol 231.1
6230-01-244-2936
1/ 2/
232.1
Complete light, Symbol 232.1
6230-00-578-7548
232.1SSL
Complete fixture, solid state, Symbol 232.1SSL
229.1SSL
Complete fixture, solid state, Symbol 229.1SSL
231.1SSL
Complete fixture, solid state, Symbol 231.1SSL
1/ 2/
001
Mounting bracket for Symbol 229.1 - two brackets
1/ 2/
002
Mounting plate for Symbol 231.1
NOTES:
1/
Formerly covered on NAVSHIPS Drawing 815-119711 and MS 17114. Symbol 234 has been
superseded by Symbol 232. Symbol 230 (M16377/27-230) has been superseded by the L. C. Doane
Co. Part Number 430, or equal.
2/
Former berth lights without receptacle (Symbol 229, NSN 6230-00-578-7547; Symbol 231,
NSN 6230-00-808-4466; and Symbol 232, NSN 6230-00-578-7548), procured for replacement
purposes for ships where isolated receptacle circuits have not been provided for berth lights, shall be in
accordance with Symbols 229.1, 231.1, and 232.1, respectively as specified herein except that the
receptacle shall not be furnished and the cable shall be a three-conductor, LSTHOF-3, in accordance
with MIL-DTL-24643/3.
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to identify changes with
respect to the previous issue due to the extent of the changes.
Custodian:
Preparing activity:
Navy SH
Navy SH
(Project 6230-2012-001)
Review activity:
DLA IS
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil.
