MIL-DTL-5003E
TABLE I. Test schedule.
Conformance
Test
Requirement
Test
First
paragraph
paragraph
article
Individual Sample
Operation
X
X
-
4.4.2.2
3.4
Operation reliability
X
-
X
4.4.2.3
3.5, 3.9
Rainfall
X
-
-
4.4.2.4
3.7, 3.9, 3.11
4.3 Conformance inspection.
4.3.1 Sampling. Sampling for examination and tests shall be in accordance with
ASQ Z1.4, inspection level S2, with the Acceptance Quality Limit (AQL) as specified in the
contract (see 6.2).
4.3.2 Examination. Sample selected in accordance with 4.3.1 shall be examined for the
defects specified in 4.4.1. Presence of one or more defects shall be cause for rejection.
4.3.3 Tests.
4.3.3.1 Individual. Each lamp assembly shall be subjected to the test specified in table I.
Failure of the test shall be cause for rejection.
4.3.3.2 Samples. Samples selected in accordance with 4.4.1 shall be subjected to the test
specified in table I. Failure of the test shall be cause for rejection.
4.4 Inspection procedure.
4.4.1 Examination. The lamp assembly shall be examined as specified herein for the
following defects:
101. Lamp assembly not as specified in figures 1 through 5 (see 3.2).
102. Materials not as specified (see 3.3).
103. Materials not resistant to corrosion and deterioration, or treated to be resistant to
corrosion and deterioration of the applicable operating and storage environment (see 3.3.1).
104. Dissimilar metals as defined in MIL-STD-889 are not effectively insulated from
each other (see 3.3.1.1).
105. Contractor does not have documentation available for identification of materials,
material finishes, or treatments (see 3.3.1.2).
106. Used, rebuilt or remanufactured components, pieces, and parts incorporated in the
lamp assembly (see 3.3.2).
107. Components not as specified (see 3.6, 3.7, 3.8, 3.9, 3.10, 3.11, 3.12, and 3.13).
108. Human Factors Engineering not as specified (see 3.14).
109. Fungus and moisture resistance treatment not as specified (see 3.15).
110. Finishes not as specified (see 3.16).
111. Identification marking not as specified (see 3.17).
112. Workmanship not as specified (see 3.18).
8
